DMP2004DWK
Maximum Ratings (@T A = +25°C, unless otherwise specified.)
Drain-Source Voltage
Gate-Source Voltage
Characteristic
Symbol
V DSS
V GSS
Value
-20
±8
Units
V
V
Drain Current (Note 4)
T A = +25 ? C
T A = +85 ? C
I D
-430
-310
mA
Thermal Characteristics (@T A = +25°C, unless otherwise specified.)
Characteristic
Total Power Dissipation (Note 4)
Thermal Resistance, Junction to Ambient
Operating and Storage Temperature Range
Symbol
P D
R θ JA
T J, T STG
Value
250
500
-65 to +150
Units
mW
°C/W
°C
Electrical Characteristics (@T A = +25°C, unless otherwise specified.)
Characteristic
Symbol
Min
Typ
Max
Unit
Test Condition
OFF CHARACTERISTICS (Note 5)
Drain-Source Breakdown Voltage
Zero Gate Voltage Drain Current
Gate-Source Leakage
BV DSS
I DSS
I GSS
-20
?
?
?
?
?
?
-1.0
? 1.0
V
μ A
μ A
V GS = 0V, I D = -250 μ A
V DS = -20V, V GS = 0V
V GS = ? 4.5V, V DS = 0V
ON CHARACTERISTICS (Note 5)
Gate Threshold Voltage
Static Drain-Source On-Resistance
Forward Transfer Admittance
Diode Forward Voltage (Note 5)
V GS(th)
R DS (ON)
|Y fs |
V SD
-0.5
?
200
-0.5
?
0.7
1.1 ?
1.7
?
?
-1.0
0.9
1.4
2.0
?
-1.2
V
?
ms
V
V DS = V GS , I D = -250 ? A
V GS = -4.5V, I D = -430mA
V GS = -2.5V, I D = -300mA
V GS = -1.8V, I D = -150mA
V DS = 10V, I D = 0.2A
V GS = 0V, I S = 115mA
DYNAMIC CHARACTERISTICS
Input Capacitance
Output Capacitance
Reverse Transfer Capacitance
C iss
C oss
C rss
?
?
?
?
?
?
175
30
20
pF
pF
pF
V DS = -16V, V GS = 0V
f = 1.0MHz
Notes:
4. Diodes Inc.'s "Green" policy can be found on our website at http://www.diodes.com.
5. Short duration pulse test used to minimize self-heating effect.
0
0
-V DS , DRAIN SOURCE VOLTAGE (V)
Fig. 1 Typical Output Characteristics
-V GS , GATE SOURCE VOLTAGE (V)
Fig. 2 Typical Transfer Characteristics
DMP2004DWK
Document number: DS30940 Rev. 6 - 2
2 of 5
www.diodes.com
January 2014
? Diodes Incorporated
